Product Features
By using a narrow pulse width laser to significantly increase the energy of a single pulse, the material can be fully vaporized in a very short period of time, and the thermal impact control effect is good
Layered multi pulse can ensure that the back of the full cut is not affected, with long focal depth, adjustable Z-axis, single pulse energy, and coating with protective liquid to ensure the cutting end face effect
Optical path design shaping and spectral processing can reduce energy loss and improve efficiency
Product Parameters
| Average Power | ≥10W |
| Pulse Energy | ≥100uJ |
| Pulse Width | ≤2ns |
| Repetition Rate | 50kHz~100kHz |
| Beam Quality | M² < 1.2 |
| Central Wavelength | 532nm, 486.1nm |
| Beam Circularities | ≥95% |
| Divergence Angle | <1mrad(full angle) |
| Power Stability | <2%RMS over 10hours |
| Pointing Stability | <50urad/°C |
| Polarization Ratio | >500:1 |
| Control Mode | Gate, Trigger |
| Dimensions | 400mm×200mm×150mm |
