Product Features
Realize laser oscillation output with a pulse width less than 2 ns and an average power greater than 7W at 50 kHz. The laser works stably for a long time in complex sea environments, with power instability less than 1% within one hour. Complete the maritime experiment of laser cross interface communication at a depth of 200 meters in the Xisha Sea area.
Product Parameters
| Average Power | ≥10W |
| Pulse Energy | ≥100uJ |
| Pulse Width | ≤2ns |
| Repetition Rate | 50kHz~100kHz |
| Beam Quality | M² < 1.2 |
| Central Wavelength | 532nm, 486.1nm |
| Beam Circularities | ≥95% |
| Divergence Angle | <1mrad(full angle) |
| Power Stability | <2%RMS over 10hours |
| Pointing Stability | <50urad/°C |
| Polarization Ratio | >500:1 |
| Control Mode | Gate, Trigger |
| Dimensions | 400mm×200mm×150mm |
